TONE

MW-100; MW-150; MW-200; MW-250; MW-300; MW-375; MW-450

Import from: Japan
Manufacturer: TONE
Model: MW-100; MW-150; MW-200; MW-250; MW-300; MW-375; MW-450

Used for tightening and loosening bolts and nuts.

The combination of the worm and the rack adjusts the opening and closing of the mouth and can be used according to the size of bolts and nuts.

A scale is attached to make it easy to adjust the size of bolts and nuts in advance

Specifications

Models	Scale display (mm)	Dimensions (mm)				Packing Quantity (Usually)	Weight (g)
		D	A	T	L
MW-100	0 ～ 12	31.5	14.5	9	110	6	50
MW-150	0 ～ 20	45.5	21.5	10	160	6	120
MW-200	0 ～ 25	58.5	25.5	13	206	6	240
MW-250	0 ～ 30	70.0	30.5	16	258	6	400
MW-300	0 ～ 35	82.0	35.5	18	304	6	650
MW-375	0 ～ 45	103.0	45.5	23	385	1	1,200
MW-450	0 ～ 55	122.0	54.5	24	465	1	2,100

※ Dimension A is the maximum opening width.
※ The tilt angle of the mouth is 15°.
※ The opening angle is 22.5°.

CAUTION

● Seize bolt/nut positively, without gap at full depth.
