SPECIFICATIONS
- 70 MPa / 700 Bar
- For Makita 18V LXT® Battery
- Usable oil capacity, 2.5 l
- Adjustable pressure 0-70 MPa
- Oil flow no load - 3,9 l/min
- Oil flow at 70 MPa - 0,28 l/min
- Ø63mm Cl. 2.5 gauge included
- 540 W at rated pressure
- Battle Hardened BLDC motor
- Weight under 13 kg
- Aluminium oil container
- Pendant control, 3m
- Can start at max. pressure
Information
Compact battery powered pump, designed to use the Makita 18V LXT® battery series. Driven by a powerful BLDC motor, battle hardened for extra durability, protected by a strong alumium container. Hold to run pendant control included.
Functionality
Low pressure oil flow between 3,9 - 3,4 l/min at 0-5 MPa and a high pressure oil flow between 0,34 - 0,28 l/min at 6-70 MPa makes every job done easy and fast. Adjustable pressure for extra control.
Usability
For intermittent use.
Industrial, workshop and in situ
aplications.
E.g:
■ Bushing tools
■ Spreaders
■ Hydraulic press
■ Hydraulic cylinders
CORDLESS HYDRAULIC PUMPS
High pressure cordless battery powered hydraulic pumps are ideal for intermittent jobs that require a combination of portability,
speed, and safety. These cordless pumps are perfect for remote locations with no access to power, but also indoors where trip
hazards, ergonomics or size is a concern. The cordless pump is compatible with all REHOBOT hydraulic tools and small to medium
sized cylinders. The Lithium-Ion battery together with a high efficiency brushless motor provides superior run time, even under
extreme job site conditions.
EXAMPLE OF RUN TIME CAPACITY:
With a 6Ah 18V Makita battery, the run time for the pump is approximatly up to 12 minutes with a fully charged battery.
At zero load pressure, that is when filling up a system or extending a piston before pressure is applied, the flow at 3,9 l/min means
you will be able to pump over 45 liters of oil in one battery charge.
At the rated pressure of 70 MPa, you will be able to pump 3,3 liters of oil in one battery charge.
Using one of REHOBOTs most popular cylinders – the CHFA182A included in REHOBOT 18 ton Bushing Tool kits – you will get a
whopping 351 strokes at zero load pressure, and 26 strokes at the full pressure of 70 MPa.
Even if using only one battery, the time needed to recharge a 6 Ah Makita battery is only 55 minutes using the Makita DC18RC
battery charger, meaning you do need to spend hours waiting before getting back in buisness again.
